Take control of creative, presentation and collaboration workspaces with Salamander’s Electric Lift Wall Stand (FPS1W-EL) stand. This Heavy-Duty stand integrates seamlessly with most large displays including 86” Screens, see VESA pattern and weight limits. Effortless precision ergonomics allow you to focus on productivity then raise your interactive display to collaborate in presentation mode.
The Salamander Electric Lift Wall Stand’s interactive display stands are crafted to be flexible and extremely durable.
Electric-lift, wall stand features an accessible, compact, low profile design that conceals all equipment and cabling. Easy to install and secure to any wall.
Ergonomically designed stand
Constructed with powder-coated welded steel and featuring industry-standard VESA mounts the FPS1W-EL stand ensures a lifetime of improved productivity, unrivalled flexibility and value.
Control your cart
Fully adjustable motor control improves user experience and productivity for any size user for any work assignment. ADA compliant. Each user can achieve their desired ergonomic setting (waist to shoulder range of movement).
State of the art wire management
Compact, Telescoping design hides cables and equipment. Wire Management allows clean and uncluttered installation. Each interactive display stand can be customized to suit your evolving work environment.
Specifications
- Durable Construction Made in the USA. Powder Coated Steel, Linak Motor Components, Powder Coated and/or Veneered MDF Panels
- VESA Pattern Horizontal – 200mm – 850mm Vertical – 200mm – 500mm Display Mounting – M4, M5, M6, M8 Screws
- Electrical Info Input: 90V – 240V ~, 48 Hz – 63HZ, IEC – Type Class 2, 2-prong, Duty Cycle: 10% Max 2min / 18min, USA Included: Available: EU (PN 400-591) UK (PN 400-592) New Zealand, Australia and others (PN 400-593)
- Display Size Range Compatible with most large displays including 86” Screens, see VESA pattern and weight limits.
- Range of Travel Center of screen: Min – 34.01” (863.8 mm) and Max 59.6” (1513.8 mm)
- Weight Capacity: Holds up to 175 lbs (80 kg)
- Product Dimensions 34.31″ W (871.5 mm) x 44.44 – 70.03″ H (1128.8 -1778.8mm) x 8.03″ D (204mm)
- VESA Compliant:
Horizontal: 200 – 850 mm
Vertical: 200 – 500 mm
- Panel Mounting – M4, M5, M6, M8 Screws
- Colour: Graphite/Gray
- Warranty: Limited Lifetime
Compatibility
- VESA compliant displays,
Horizontal – 200mm, 300mm, 350mm, 400mm, 600mm, Vertical – 200mm, 300mm, 350mm, 400mm
- Microsoft Surface Hub 2S – Adapters included and sold separately (Product No. CA/MAC4), call for details.
- Cisco Webex Boards – Cisco Webex Board 55″ Stand, see model FPS1/ELCS/GG
Cisco Webex Board Adapters for 70″and 85″ available (Product No. CA/MAC2 and CA/MAC3), call for details.
Ergonomics
- Fully adjustable motor control improves user experience and productivity for any size user for any work assignment.
- ADA compliant. Each user can achieve their desired ergonomic setting (waist to shoulder range of movement).
Deployment
- FPS1W-EL stand saves on engineering, trades and permitting as there no need to mount display to a wall.
Design & Construction
- Constructed with powder-coated welded steel and featuring industry-standard VESA mounts the FPS1W-EL stand ensures a lifetime of improved productivity, unrivalled flexibility and value.
- Custom finishes and custom-matched wood panels are available.
Download the Assembly Instructions
Download the Spec Sheet
